Material: | PE | Connection: | Buttfusion |
---|---|---|---|
Shape: | Reducer | Product Name: | Hdpe Fusion Fittings Buttwelding Joint Fittings Pe100 Reducer |
SDR: | SDR17.6 SDR11 | Color: | Black Or As Customized |
Reducer Coupling Details
Products name | Buttfusion Reducer Coupling |
Sizes Available | 63-80mm |
SDR | SDR11 SDR17 |
PN | PN16 PN10 |
Material Brand | 3490/3440 |
Executive Standard | EN 12201-3:2011,EN 1555-3:2010,ISO |
Colors Available | Black color , blue color, Orange or as request. |
Packing Method | Normal export packing. by carton |
Certificate | ISO, CE |
Supply Ability | 100000 Ton/Year |
Payment Method | T/T, L/C at sight |
Trading Method | EXW, FOB, CFR, CIF |
(1) Black PE pipe fittings are UV resistant, resistant to aging and have a service life of up to 30 years.(2) Smooth inner wall, low frictional resistance, energy saving, good hygienic performance, no additives(3) Polyethylene pipe fittings can be welded to the pipe joints to form an organic whole, without the possibility
of joint leakage, saving water, reducing operating costs and maintenance costs.(4) The installation of PE pipes can be welded or fused to form a completely enclosed anti-seepage system.(5) Good low temperature resistance, corrosion resistance, long life, buried pipelines in the temperature range of -40 ° C and 40 ° C
specifications | L
mm |
L1
mm |
L2
mm |
S63×25 | 125 | 65 | 41 |
S63×32 | 128 | 65 | 44 |
S63×40 | 133 | 65 | 49 |
S63×50 | 150 | 65 | 55 |
S75×32 | 135 | 70 | 44 |
S75×40 | 140 | 70 | 49 |
S75×50 | 145 | 70 | 55 |
S75×63 | 150 | 70 | 60 |
S90×32 | 155 | 80 | 44 |
S90×40 | 165 | 80 | 49 |
S90×50 | 170 | 80 | 55 |
S90×63 | 175 | 80 | 65 |
S90×75 | 175 | 80 | 70 |
S110×40 | 160 | 82 | 49 |
S110×50 | 165 | 82 | 55 |
S110×63 | 175 | 82 | 65 |
S110×75 | 175 | 82 | 65 |
S110×90 | 175 | 82 | 65 |
S125×63 | 190 | 85 | 65 |
S125×75 | 131 | 60 | 50 |
S125×90 | 190 | 85 | 80 |
S125×110 | 190 | 85 | 80 |
S140×50 | |||
S140×63 | 220 | 92 | 63 |
S140×90 | 225 | 92 | 80 |
S140×110 | 225 | 92 | 80 |
S160×32 | 180 | 100 | 44 |
S160×63 | 200 | 100 | 63 |
S160×75 | 205 | 100 | 70 |
S160×90 | 115 | 100 | 82 |
S160×110 | 200 | 100 | 85 |
S160×125 | 200 | 100 | 85 |
S180×90 | 225 | 105 | 75 |
S180×110 | 225 | 105 | 80 |
S180×125 | 147 | 65 | 65 |
S180×160 | 225 | 105 | 85 |
S200×63 | 210 | 110 | 63 |
S200×90 | 225 | 110 | 79 |
S200×110 | 230 | 110 | 85 |
S200×125 | 157 | 65 | 60 |
S200×160 | 220 | 110 | 85 |
S225×110 | 250 | 105 | 82 |
S225×160 | 250 | 105 | 90 |
S225×200 | 250 | 105 | 90 |
S250×110 | 225 | 105 | 82 |
S250×125 | 225 | 105 | 82 |
S250×160 | 240 | 105 | 98 |
S250×200 | 245 | 105 | 105 |
S250×225 | 151 | 75 | 65 |
S280×160 | 250 | 110 | 90 |
S280×200 | 250 | 105 | 90 |
S280×225 | 250 | 105 | 95 |
S280×250 | 250 | 110 | 90 |
S315×90 | 230 | 110 | 79 |
S315×110 | 240 | 110 | 82 |
S315×160 | 250 | 110 | 100 |
S315×180 | 250 | 120 | 95 |
S315×200 | 250 | 100 | 95 |
S315×225 | 250 | 100 | 110 |
S315×250 | 250 | 100 | 100 |
S355×200 | 270 | 100 | 100 |
S355×250 | 270 | 100 | 100 |
S355×315 | 240 | 100 | 100 |
S400×200 | 250 | 100 | 100 |
S400×250 | 250 | 100 | 100 |
S400×315 | 250 | 100 | 100 |
S400×355 | 250 | 100 | 100 |
S450×200 | 260 | 100 | 100 |
S450×250 | 260 | 100 | 100 |
S450×315 | 250 | 100 | 100 |
S450×355 | 250 | 100 | 100 |
S450×400 | 240 | 100 | 100 |
S500×315 | 225 | 80 | 80 |
S500×355 | 226 | 80 | 95 |
S500×400 | 250 | 100 | 100 |
S500×450 | 250 | 100 | 100 |
S560×355 | 247 | 80 | 95 |
S560×400 | 236 | 80 | 100 |
S560×450 | 199 | 80 | 80 |
S560×500 | 260 | 100 | 100 |
S630×400 | 261 | 80 | 100 |
S630×450 | 223 | 80 | 80 |
S630×500 | 260 | 100 | 100 |
S630×560 | 145 | 80 | 40 |
